Purpose-built for the RFID electronic tag industry: integrates feeder card splitting, vacuum adsorption conveying, imported servo single/multi-row RFID tag application, German photoelectric tracking, and automatic collection.
RFID Intelligent Paper Card Labeling Machine (T-118) achieves ±1mm (excluding product & label tolerances) labeling accuracy at speeds of 30–80 pcs/min (related to sheet & tag layout). Applicable product size: L: 200–550mm | W: 200–520mm (customizable); label size: Length: 30–100mm | Backing Width: 15–100mm; machine footprint: 6000 × 1200 × 1500 mm (L×W×H) (AC 110–380V / 50Hz | Air Pressure: 0.6–0.8 MPa, Approx. 200 kg).
Standard factory configuration parameters. Non-standard dimensions and speed upgrades can be customized.
| Parameter | Specification Value | Engineering Note |
|---|---|---|
| Model Code | T-118 | Dongguan Henglitong Standard / Custom Series |
| Labeling Accuracy | ±1mm (excluding product & label tolerances) | Servo / Stepper Closed-Loop Control |
| Labeling Speed | 30–80 pcs/min (related to sheet & tag layout) | Adjustable via PLC Touch Screen |
| Applicable Product Size | L: 200–550mm | W: 200–520mm (customizable) | Custom fixtures available for special shapes |
| Applicable Label Size | Length: 30–100mm | Backing Width: 15–100mm | Supports opaque or transparent self-adhesive labels |
| Machine Dimensions (L×W×H) | 6000 × 1200 × 1500 mm (L×W×H) | Heavy-duty stainless steel & anodized aluminum frame |
| Power Supply | AC 110–380V / 50Hz | Air Pressure: 0.6–0.8 MPa | 110V/220V/380V 50/60Hz configurable for destination country |
| Net Weight | Approx. 200 kg | Export fumigation-free wooden crate packaging |
| Label Roll Inner Core | Ø76 mm | Standard industrial roll core |
| Label Roll Max Outer Dia. | Max. Ø350 mm | High-capacity unwind disc |
| Optional Configurations & Coding | Single-row or multi-row imported servo RFID tag applicator; Feeder card splitting + vacuum adsorption conveyor + automatic stacking collection; 50-preset PLC touch HMI | Ribbon coder, inkjet, vision inspection, inline conveyor |
| Target Industries | RFID Electronic Tags & Smart Cards, Apparel & Retail Hangtags, Aviation & Logistics Tags, Printing & Packaging | 74+ verified industry cases available |
This model handles container dimensions within the specified range above and supports custom starwheels, centering chains, or contoured fixtures for special shapes. It can run standalone or connect directly to upstream filling/capping conveyors.
Actual throughput (pcs/min) depends on container length, label web length, and feeding method. Provide your container L×W×H (or diameter), label L×W, and winding direction so our engineers can calculate your exact line cycle rate.
We offer thermal ribbon coders, hot-stamp printers, CIJ/TIJ inkjet integration, transparent-label optical sensors, vision barcode inspection, NG rejection, and 110V/220V/380V country-specific electrical standards.
Simply submit the RFQ form below or contact us on WhatsApp (+86 137-1277-8919). Ship 20–50 sample containers and 1 label roll to our Dongkeng, Dongguan factory—we will record a full HD test-labeling video for your approval free of charge.
Our 10-person senior mechanical & PLC team (8+ years experience) oversees your project. Every shipment includes full FAT video verification, English/localized operation manuals, circuit schematics, toolkits, and 1-on-1 remote video commissioning.
