High-speed top-plane inline labeling head (40–300 pcs/min) that mounts over existing packaging conveyors, inkjet belts, or assembly lines to apply self-adhesive labels, films, barcodes, and QR codes.
Upper Plane Assembly Line Labelling Head (T511) achieves ±1mm (excluding product & label tolerances) labeling accuracy at speeds of 40–300 pcs/min (related to conveyor & label size). Applicable product size: L: 40–400mm | W: 30–500mm | H: 60–380mm; label size: Length: 10–250mm | Width: 10–175mm; machine footprint: 1100 × 700 × 1000 mm (L×W×H) (AC 110–220V / 50Hz, Approx. 180 kg).
Standard factory configuration parameters. Non-standard dimensions and speed upgrades can be customized.
| Parameter | Specification Value | Engineering Note |
|---|---|---|
| Model Code | T511 | Dongguan Henglitong Standard / Custom Series |
| Labeling Accuracy | ±1mm (excluding product & label tolerances) | Servo / Stepper Closed-Loop Control |
| Labeling Speed | 40–300 pcs/min (related to conveyor & label size) | Adjustable via PLC Touch Screen |
| Applicable Product Size | L: 40–400mm | W: 30–500mm | H: 60–380mm | Custom fixtures available for special shapes |
| Applicable Label Size | Length: 10–250mm | Width: 10–175mm | Supports opaque or transparent self-adhesive labels |
| Machine Dimensions (L×W×H) | 1100 × 700 × 1000 mm (L×W×H) | Heavy-duty stainless steel & anodized aluminum frame |
| Power Supply | AC 110–220V / 50Hz | 110V/220V/380V 50/60Hz configurable for destination country |
| Net Weight | Approx. 180 kg | Export fumigation-free wooden crate packaging |
| Label Roll Inner Core | Ø76 mm | Standard industrial roll core |
| Label Roll Max Outer Dia. | Max. Ø300 mm | High-capacity unwind disc |
| Optional Configurations & Coding | Cantilever height & horizontal handwheel adjustment; Replaceable pressing mechanism for uneven surfaces; Thermal coder or inkjet printer | Ribbon coder, inkjet, vision inspection, inline conveyor |
| Target Industries | Packaging Conveyor Retrofits, Printing, Books & Folders, Electronics & 3C Lines, Food & Pharmaceutical Lines, Carton & Case Lines | 74+ verified industry cases available |
This model handles container dimensions within the specified range above and supports custom starwheels, centering chains, or contoured fixtures for special shapes. It can run standalone or connect directly to upstream filling/capping conveyors.
Actual throughput (pcs/min) depends on container length, label web length, and feeding method. Provide your container L×W×H (or diameter), label L×W, and winding direction so our engineers can calculate your exact line cycle rate.
We offer thermal ribbon coders, hot-stamp printers, CIJ/TIJ inkjet integration, transparent-label optical sensors, vision barcode inspection, NG rejection, and 110V/220V/380V country-specific electrical standards.
Simply submit the RFQ form below or contact us on WhatsApp (+86 15549490127). Ship 20–50 sample containers and 1 label roll to our Dongkeng, Dongguan factory—we will record a full HD test-labeling video for your approval free of charge.
Our 10-person senior mechanical & PLC team (8+ years experience) oversees your project. Every shipment includes full FAT video verification, English/localized operation manuals, circuit schematics, toolkits, and 1-on-1 remote video commissioning.
